R32 Split Set

Name: R32 Split Set
Brand: GZ AXEN Heat Pump Technology CO.,LTD.

AXEN R32 Split Air to Water Heat Pump: Features separate indoor and outdoor units with hydronic components housed indoors, providing efficient heating and cooling even in freezing temperatures.

Contact AXEN +

Specifications of R32 Split Set

Model name		OUTDOOR	KFS-40W/N8BP	KFS-60W/N8BP	KFS-80W/N8BP	KFS-100W/N8BP	KFS-120W/N8BP	KFS-140W/N8BP	KFS-160W/N8BP	KFS-100W/N8SBP	KFS-120W/N8SBP	KFS-140W/N8SBP	KFS-160W/N8SBP
Model name		INDOOR	KFS-40B/EN8BP	KFS-60B/EN8BP	KFS-80B/EN8BP	KFS-100B/EN8BP	KFS-120B/EN8BP	KFS-140B/EN8BP	KFS-160B/EN8BP	KFS-100B/EN8SBP	KFS-120B/EN8SBP	KFS-140B/EN8SBP	KFS-160B/EN8SBP
Power supply		V / Ph / H	220-240 / 1 / 50							380-415 /3 / 50
Heating1	Capacity	kW	4.2	6.0	7.9	9.7	12.1	14.3	16.2	9.7	12.1	14.3	16.2
Heating1	COP		4.89	4.89	4.52	4.61	4.52	4.61	4.41	4.61	4.52	4.61	4.41
Heating2	Capacity	kW	4.1	6.1	8.3	9.9	11.6	14.5	16.2	9.9	11.6	14.5	16.2
Heating2	COP		3.47	3.58	3.45	3.48	3.17	3.72	3.62	3.48	3.17	3.72	3.62
Heating3	Capacity	kW	4.0	6.2	8.0	9.9	11.7	13.8	16.2	9.9	11.7	14.1	16.2
Heating3	COP		2.42	2.84	2.70	2.77	2.72	3.12	2.90	2.77	2.72	3.12	2.90
Cooling4	Capacity	kW	4.2	6.2	8.1	10.3	12.1	13.5	14.9	10.3	12.1	13.5	14.9
Cooling4	EER		5.41	4.81	4.59	4.58	4.04	3.65	3.41	4.58	4.04	3.65	3.41
Cooling5	Capacity	kW	4.2	6.0	7.7	9.6	10.9	12.7	14.0	9.6	10.9	12.7	14.0
Cooling5	EER		3.12	2.94	2.78	2.94	2.66	2.55	2.45	2.94	2.66	2.55	2.45
Seasonal space heating energy efficiency class	LWT at 35℃		A+++	A+++	A+++	A+++	A+++	A+++	A+++	A+++	A+++	A+++	A+++
Seasonal space heating energy efficiency class	LWT at 55℃		A++	A++	A++	A++	A++	A++	A++	A++	A++	A++	A++
Refrigerant	Type		R32	R32	R32	R32	R32	R32	R32	R32	R32	R32	R32
Refrigerant	Charged	kg	1.40	1.40	1.50	1.60	1.75	1.84	1.84	1.60	1.75	1.84	1.84
GWP value			675	675	675	675	675	675	675	675	675	675	675
Equivalent CO2		Ton	0.945	0.945	1.013	1.080	1.181	1.242	1.242	1.080	1.181	1.242	1.242
	Quantity		1	1	1	1	1	1	1	1	1	1	1
	Quantity		1	1	1	1	1	1	1	850	850	825	825
Piping connections	Liquid Dia .(OD)	mm	Φ6.35	Φ6.35	Φ9.52	Φ9.52	Φ9.52	Φ9.52	Φ9.52	Φ9.52	Φ9.52	Φ9.52	Φ9.52
Piping connections	Gas Dia.(OD)	mm	Φ15.88	Φ15.88	Φ15.88	Φ15.88	Φ15.88	Φ15.88	Φ15.88	Φ15.88	Φ15.88	Φ15.88	Φ15.88
Sound power level6	INDOOR	dB	42	42	42	42	42	42	42	42	42	42	42
Sound power level6	OUTDOOR	dB	56	58	59	60	64	65	68	60	64	65	68
Operating temperature	Cooling	℃	-5 to 43
	Heating	℃	-25 to 35
	DHW	℃	-25 to 43
Note:
1. Outdoor air temperature 7℃ DB, 85% R.H; EWT 30℃, LWT 35℃
2. Outdoor air temperature 7℃ DB, 85% R.H; EWT 40℃, LWT 45℃
3. Outdoor air temperature 7℃ DB, 85% R.H; EWT 47℃, LWT 55℃
4. Outdoor air temperature 35℃ DB, 85% R.H; EWT 23℃, LWT 18℃
5. Outdoor air temperature 35℃ DB, 85% R.H; EWT 12℃, LWT 7℃
6. Test standard:EN12102-1

Besides R32 air to water heat pumps, AXEN provides R290 monobloc heat pump, R290 Hydro Split and All In One ecoflow heat pump and many other kinds as well.
